Product Summary
The OP37AJ/883 is a precision operational amplifier, which provides lower noise and higher speed with the same input offset and drift specifications as the OP07. Both parts have a 10 μV offset, 0.2μV/℃ drift, and 1.8 million gain. The applications of the OP37AJ/883 include low-noise DC amplifiers, microphone amplifiers, precision amplifiers, tape-head preamplifiers, thermocouple amplifiers.
Parametrics
OP37AJ/883 absolute maximum ratings: (1)supply voltage: ±22 V; (2)input voltage: ±22 V; (3)output short-circuit duration: continuous; (4)differential input voltage: 0.7 V; (5)differential input current: ±25 mA; (6)continuous power dissipation: 727 mW at plastic DIP; (7)operating temperature ranges: -55 to +150 ℃; (8)junctioan temperature range: -65 to +150 ℃; (9)storage temperature range: -65 to +150 ℃; (10)lead temperature: +300 ℃.
Features
OP37AJ/883 features: (1)10μV input offset voltage; (2)0.2μV/℃ drift; (3)3nV√Hz input noise voltage (1kHz); (4)80nVp-p noise (0.1Hz to 10Hz); (5)17V/μs slew rate; (6)63MHz gain-bandwidth product.
Diagrams
 |
