Product Summary
The SKKT273/16E is a Thyristor / Diode Module. The applications of the SKKT273/16E include DC motor control (e.g. for machine tools), Temperature control (e.g. for ovens, chemical processes), Professional light dimming (studios, theaters).
Parametrics
SKKT273/16E absolute maximum ratings: (1)ITAV: 273 A at sin. 180; Tc = 85℃; (2)ITSM: 9000 A at Tvj = 25 ℃; 10 ms, 8000 A at Tvj = 130 ℃; 10 ms; (5)i2t: 405000 A2s at Tvj = 25 ℃; 8,3 ... 10 ms, 320000 A2s at Tvj = 130 ℃; 8,3 ... 10 ms; (6)VT: 1.6 V max at Tvj = 25 ℃; IT = 750 A; (7)VT(TO): 0.9 V max at Tvj = 130 ℃; (8)rT: 0.92 mΩ max at Tvj = 130 ℃.
Features
SKKT273/16E features: (1)Industrial standard package;(2)Heat transfer through aluminium oxide ceramic isolated metal base plate; (3)Thyristor with center gate; (3)UL recognized, file no. E 63 532.
Diagrams
 |
