Product Summary

The XC6202P302MR is a highly precise, low power consumption, high voltage input, positive voltage regulator manufactured using CMOS and laser trimming technologies. The XC6202P302MR consists of a current limiter circuit, a driver transistor, a precision reference voltage and an error correction circuit. Output voltage is selectable in 100mV steps from 1.8V ~ 18V. The device is also compatible with low ESR ceramic capacitors which give added output stability. The applications of the XC6202P302MR include: Battery powered equipment, Reference voltage, Cameras, video cameras, Palmtops.

Parametrics

XC6202P302MR absolute maximum ratings: (1)Input Voltage VIN: 22.0 V; (2)Output Current IOUT: 500 mA; (3)Output Voltage VOUT: VSS-0.3 to VIN+0.3 V; (4)Power Dissipation Pd: SOT-25: 150mW; SOT-89: 500mW; TO-92: 300mW; USP-6B: 100mW; SOT-223: 1,200mW; (5)Operating Temperature Range Topr: -40 to +85 ℃; (6)Storage Temperature Range Tstg: -55 to +125 ℃.

Features

XC6202P302MR features: (1)Maximum Output Current: 150mA (within Pd); (2)Maximum Operational Voltage: 20V; (3)Output Voltage Range: 1.8V to 18V (0.1V increments); (4)Highly Accurate: ±2%; (5)Low Power Consumption: 10μA (TYP.); (6)Line Regulation: 0.01% / V (TYP.); (7)Dropout Voltage: 200mV @ 30mA; 670mV@100mA; (8)Operational Temperature Range: -40℃ to 85℃; (9)Low ESR Capacitor Compatible: Ceramic capacitor; (10)Current Limiter Circuit Built-In Small Packages: SOT-23 (150mW),SOT-89 (500mW), TO-92 (300mW), SOT-223 (1200mW), USP-6B (100mW).

Diagrams

XC6202P302MR block diagram
