Product Summary
The ACS402-5SB4 is a quad AC line switch array. It belongs to the AC line switches array family built around the ASD concept. This high performance planar technology device ACS402-5SB4 includes 4 bi-directional a.c. switches able to control an 0.2 A resistive or inductive load. The applications of the ACS402-5SB4 are solenoid, relay, valve, dispenser, micro-motor, door lock, low power lamp bulb, pump, fan.
Parametrics
ACS402-5SB4 absolute maximum ratings: (1)Repetitive peak off-state voltage:500V; (2)RMS on-state current full cycle sine wave 50 to 60 Hz:0.2A; (3)Critical rate of rise of on-state current:20A/us; (4)Non repetitive line peak pulse voltage:2kV; (5)Storage temperature range:-40 to +150℃; (6)Operating junction temperature range:0 to +110℃; (7)Maximum lead temperature for soldering during 10s:260℃.
Features
ACS402-5SB4 features: (1)4 high voltage AC switch array; (2)VDRM /VRRM = 500V; (3)Avalanche controlled device; (4)IT(RMS) = 0.2 A per switch; (5)IT(RMS) = 0.4 A for the total array; (6)Gate triggering current : IGT <10mA; (7)Switch integrated driver.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 ACS402-5SB4 |
STMicroelectronics |
Triacs 0.2A 500V AC Line Sw |
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
ACS401 |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
ACS402-5SB4 |
STMicroelectronics |
Triacs 0.2A 500V AC Line Sw |
Data Sheet |
Negotiable |
|
||||
|
ACS406CS |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
ACS411CS |
Other |
|
Data Sheet |
Negotiable |
|
||||
